| Multi-protocol digital radio - designed to operate under an NXDN and FM analogue protocols |
| NXDN Conventional Operation |
| Mixed Digital & FM Analogue Operation allows gradual migration at your own pace |
| 7-color Light Bar Indicator on the top panel |
| Renowned KENWOOD Audio Quality - TX/RX audio profile with Optimizable digital processor |
| Emergency Function - customizable Emergency Profile |
| 2-pin Audio Accessory Connector |
| Easy Visible Display - 8-digit LCD model featuring high-contrast, white backlit LCD |
| Standard Keypad |
| Full details of all the NEXEDGE features available from your Kenwood dealer | Yes |
| All Group Call | Yes |
| AMBE+2 Vocoder | Yes |
| Broadcast Call (Trunking Mode) | Yes |
| Emergency Call | Yes |
| Group Call (Trunking Mode) | Yes |
| Individual Private Call (Trunking Mode) | Yes |
| Individual Call | Yes |
| NXDN Conventional Included | Yes |
| Type-D Trunking | Yes |
| NXDN Digital 12.5/6.25kHz Channel Spacing | Yes |
| NXDN Scrambler Included | Yes |
| Over-the-air Alias | Yes |
| Paging Call | Yes |
| Priority Monitor IDs | Yes |
| Radio Access Numbers (RAN) | Yes |
| Remote Monitoring | Yes |
| Remote Stun/Kill | Yes |
| Short & Long Data Messages | Yes |
| Status Messaging | Yes |
| Zones | 128 |
| For use in the EU | Yes |
| IP54 | Yes |
| IP55 | Yes |
| MIL-STD 810 C/D/E/F/G | Yes |
| Frequency Range | 400 - 470 MHz |
| Number of Channels | 260 |
| Number of Zones | 128 |
| Channel Spacing - Analogue - Wide/Mid/Narrow | 25 kHz/20 kHz/12.5 kHz |
| Channel Spacing - Digital - Wide/Narrow | 12.5 kHz/6.25 kHz |
| Battery Life | With KNB-45L: ± 11.0 h (FDMA) With KNB-53N: ± 7.0 h (FDMA) With KNB-69L: ± 14.0 h (FDMA) - 5-5-90 - |
| Frequency Stability | ± 0.5 ppm (-30 °C to + 60 °C) |
